Electric Overhead Travelling Crane from China manufacturer

Price:	5000.0~500000.0 USD
Payment Terms:	T/T,L/C,WU,
Special Groups:	overhead crane (2)
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: explosion-proof single gird...

Production Capacity: as your required

Delivery Date: as your required

Power Source: Electric

Brand Name: HENGSHENG

Maximum Lifting Height: 30M

overhead crane: single beam crane

Means of Transport: Ocean,

Packing: bulk

Sling Type: Others

Usage: Construction Hoist

Maximum Lifting Weight: 20T

Lift Speed: 8(8/0.8)

electric single beam crane: explosion-proof single gird...

LDA type crane is designed on the basis of LD type crane, characterized by the features of reasonable structure and strong rigidity.CD1 and MD1 hoists

Features:

1) Reasonable structure
2) Favorable performance
3) Smooth starting and stopping
4) Safe and reliable traveling
5) Low noise, commodious cabin and good view
6) Convenient maintenance, excellent exchangeability for parts and components
7) energy-saving

Lifting weight (t)	1-10
Span(m)	7.5-22.5
Traveling speed of crane(m/min)	20- 75
Traveling speed of hoist(m/min)	20 30
Lifting speed(m/min)	8(8:0.8)
Lifting height(m)	6-30
Working system	A3-A5
Power supply	A.C. 3phase 50hz 380 v

LD type 10-16t electric single beam crane

Lifting weight (t)	10-16
Span(m)	7.5-31
Traveling speed of crane(m/min)	58.78	15.88-26.26	39.38
Traveling speed of hoist(m/min)	20(30)
Lifting speed (m/min)	3.5(3.5/0.35)
Lifting height(m)	12-30
Working system	A3-A5
Power supply	A.C. 3phase 50hz 380 v

LD type 20t electric single beam crane

Lifting weight (t)	20
Span(m)	7.5-31
Traveling speed of crane (m/min)	15.88-58.88
Lifting speed(m/min)	3.5(3.5:0.35)
Lifting height(m)	12-30
Working system	A3-A5
Power supply	A.C. 3phase 50hz 380 v

LH type electric hoist E.O.T crane

Lifting weight (t)	5	10	16	20
Span(m)	10.5-31.5	10.5-31.5	10.5-31.5	10.5-31.5
Traveling speed of trolley	20	20	20	20
Lifting speed(m/min)	78(8:0.8)	87(7:0.7)	83.5(3.5:0.35)	86(6:0.6)
Lifting height	69-18	99-18	99-18	96-18
Power supply	A.C. 3phase 50hz 380 v

LX single beam suspension crane

Lifting weight (t)	1-5
Span(m)	3-16	3-16
Traveling speed of crane(m/min)	20 30
Traveling speed of hoist	20 30
Lifting speed(m/min)	8(8:0.8)
Lifting height	6 -30
Working system	Medium(JC=20)
Power supply	A.C. 3phase 50hz 380 v

LX single beam suspension motor crane and CD1, MD1 model electric hoist are used together as a whole set. It is a light duty track crane applied to machinery, assembling and warehouses. This product adopts ground control and works at a temperature of -25℃to 40℃. It is prohibited to use the equipment at combustible, explosive or corrosive environment.

LDX type electric single beam crane

Lifting weight (t)	1-10
Span(m)	7.5-22.5
Lifting speed(m/min)	7
Lifting height(m)	9-30
Working system	A1-A5
Power supply	A.C. 3phase 50hz 380 v

LB explosion-proof single girder electric crane

LB model single girder suspended crane are used together with HB and HS electric hoist as a whole set. As a light duty carne traveling on track, it is widely applied to machinery, assembling, warehouse. It is handled by ground control in an environment with the temperature from minus 25 degree to plus 40 degree.

Lifting weight (t)	0,5,1,2,3,	5
Span(m)	3-6	3-6
Traveling speed of crane(m/min)	20	30
Traveling speed of electric hoist(m/min)
Lifting speed(m/min)	8(8:0.8)
Lifting height	6 -30
Working system	Medium(JC=25)
Power supply	A.C. 3phase 50hz 380 v
